2932-00 Multicore Cable, 8-channels | Black 1mt

Ürün Açıklaması

Mogami 2932-00 Multicore Cable, 8-channels | Black 1mt 8-Kanal Multicore Kablo Ø 11,5 mm | Renk Siyah 1mt Teknik Özellikler • color: Siyah • no. of conductor: 8 x 2 • cable diameter: 11,5 mm • series: Multicore • inner conductor: Details: 30 x 0,08 A / Size: 0,15 mm² (AWG26) • insulation: Ov. Dia.: 1 mm / Material: XLPE / Farbe: Resistor Colorcode/Clear • 2. insulation: Ov. Dia.: 2,8 mm / Material: Flexible PVC / Farbe: Resistor Colorcode • drain wire: Details: 7 x 0,18 TA / Size: 0,18 mm² (AWG25) • shielding: Spiralshield (60 x 0,1 A) • DC resistance: Inner Conductor: 0,130 Ohm/m / Shield: 0,030 Ohm/m • capacity (1 kHz, 20°C): Inner Conductor-Shield: 130 pF/m / Conductor-Conductor: 12 pF/m • applicable temperature: -20°C - +70°C • jacket material: Flexible PVC • Kablo no.: 2932 • Ağırlık: 0,18 kg
